Data Sheet

ROCKER SWITCH SPDT ON-NONE-ON MINIATURE SNAP-IN
16A 125VAC BLACK ACTUATOR .250 INCH QC TERMINALS

Current Rating: 16A 125VAC, 10A 250VAC, 3/4 HP 125-250VAC
10(4)A 250VAC T85
Insulation Resistance: 100 Megohms (min.)
Dielectric Strength: 1000V RMS (min.)
Temperature Rating: +32 to +185 F (0 to +85 C)
Electrical Life: 100,000 cycles
Mechanical Life: 100,000 cycles
Terminal Type: 0.250” Tab Q.C.
Mounting Hole: 1.125" (28.58mm) x 0.550" (13.97mm)

Additional Model #'s
75-54-061
75-54061
54-061
54061

UPC: 768249071440
