Data Sheet

NTE712
Integrated Circuit
TV/FM Sound IF Detector

Description:
The NTE712 is a versitile device in a 14-Lead DIP type package incorporating IF limiting, detection, electronic attenuation, audio amplifier, and audio driver capabilities.

Features:
Differential Peak Detector Requiring a Single Tuned Circuit
Electronic Attenuator Replaces Conventional AC Volume Control: Range > 60dB
Excellent AM Rejection @ 4.5 and 5.5MHz
High Stability
Low Harmonic Distortion
Audio Drive Capability: 6.0mAP-P
Minimum Undesirable Output Signal @ Maximum Attenuation

Replaces:
ECG712, GEIC-2, SK3072
