Data Sheet

NTE709
Integrated Circuit
TV/FM Sound IF Amplifier

Description:
The NTE709 is a monolithic integrated circuit in a 14-Lead DIP type package providing a multi-stage wideband amplifier/limiter, an FM quadrature detector, and an emitter-follower audio output stage and is designed for use in FM receivers or in sound IF of TV receivers.

Features:
Good Sensitivity
Excellent AM Rejection
Low Harmonic Distortion
Single-Adjustment Timing
High gain to 50MHz
500mV Recovered Audio at 10.7MHz
Wide Operating Voltage Range

Replaces:
ECG709, GEIC-11, SK3135

Additional Model #'s
76-NTE709
NTE709

UPC: 768249292517
