Data Sheet

NTE1294
Integrated Circuit
Audio Power Amplifier, 1.2W

Description:
The NTE1294 is a monolithic integrated audio amplifier in an 8-Lead DIP type package designed for
use as a low frequency class B power amplifier with a wide supply voltage range (3V to 16V) in portable radios, cassette recorders, and players etc.

Features:
Minimum Working Supply Voltage: Vs = 3V Min
Low Quiescent Current
Low Number of External Components
Good Ripple Rejection
No Cross-over Distortion
Low Power Dissipation
Output Power:
Po = 2W at 12V/8?
Po = 1.6W at 9V/4?
Po = 1.2W at 9V/8?

Replaces:
ECG1294

Additional Model #'s
76-NTE1294
NTE1294

UPC: 768249026815
