Data Sheet

NTE804
Integrated Circuit
Dual Audio Power Amp, 2W

Description:
The NTE804 is a monolithic dual power amplifier which offers high quality performance for stereo
phographs, tape players, recorders and AM-FM stereo receivers, etc.

The NTE804 will deliver 2W/channel into 8 or 16? loads. The amplifier is designed to operate with
a minimum of external components and contains an internal bias regulator to bias each amplifier.
Device overload protection consists of both internal current limit and thermal shutdown.

Features:
AVO = 90dB Typ
2W Per Channel
70dB Ripple Rejection
75dB Channel Separation
Internal Stabilization
Self Centering Biasing
3M? Input Impedance
10-26V Operation
Internal Current Limiting
Internal Thermal Protection

Applications:
Multi-Channel Audio System
Tape Recorders and Players
Movie Projectors
Automotive System
Stereo Phonographs
Bridge Output Stages
AM-FM Radio Receivers
Intercoms
Stereo Amplifiers
Instrument Systems
