NTE367 T-NPN, Si, RF Power Output (PO 45W 407-512MHZ)

Model: NTE367
Availability :  In Stock
  • NTE367 T-NPN, Si, RF Power Output (PO 45W 407-512MHZ)
  • NTE367 T-NPN, Si, RF Power Output (PO 45W 407-512MHZ)
  • NTE367 T-NPN, Si, RF Power Output (PO 45W 407-512MHZ)
$85.99
Current Reviews: 0 Add Your Review
QTY :

Data Sheet

NTE367
Silicon NPN Transistor
RF Power Amplifier
PO = 45W @ 512MHz

Description:
The NTE367 is a silicon NPN RF power transistor in a W65 type package designed for 12.5V UHF large-signal amplifier applications in industrial and commercial FM equipment operating to 512MHz.

Features:
Specified 12.5V, 470MHz Characteristics:
Output Power: 45W
Minimum Gain: 4.8dB
Efficiency: 55%
Characterized with Series Equivalent Large-Signal Impedance Parameters
Built-In Matching Network for Broadband Operation
Tested for Load Mismatch Stress at all Phase Angles with 20:1 VSWR @ 16V High Line and 50% Overdrive

Replaces:
ECG367

Additional Model #'s
76-NTE367
NTE367

UPC: 768249146919
