Data Sheet

ROCKER SWITCH ILLUMINATED SPST MINIATURE SNAP-IN OFF-NONE-ON
10A 12VDC RED LENS 12V INCAN LAMP .250

Specifications
Current Rating: 10A 12VDC
Lamp Voltage: 12V Incandescent
Insulation Resistance: 100 Megohms (min.)
Dielectric Strength: 1000V RMS (min.)
Temperature Rating: +32 to +185 F (0 to +85 C)
Electrical Life: 100,000 cycles
Mechanical Life: 100,000 cycles
Terminal Type: 0.250” Tab Q.C.
Mounting Hole: 1.125' (28.58mm) x 0.550" (13.97mm)

Additional Model #'s
75-54-083
75-54083
54-083
54083

UPC: 768249073642
