Manual/Spec Sheet

Electrical Properties
Impedance: 50 Ohms
Capacitance Conductor to Shield: 88 pf/m

Construction Details
Center Conductor: 20awg (19/0.18mm) Stranded Tinned Copper Wire

Dielectric: Gas Expanded Polyethylene
Nominal Diameter Over Dielectic: 2.79 mm

Shield:
1st Shield: Aluminum Mylar Tape with overlap Bonded
2nd Shield: Tinned Copper Wire Braid Shield 90% Coverage

Jacket: PVC
Nominal Diameter Over Jacket: 4.90 mm
Nominal Jacket Thickness: 0.80 mm

Listing and Ratings: UL Type AWM

Additional Model #'s
215-S-BNC58A-25
215-SBNC58A25
S-BNC58A-25
SBNC58A25

UPC: 725310130444
