Data Sheet

NTE801
Integrated Circuit
FM Stereo Demodulator

Description:
The NTE801 is a monolithic device in a 14-Lead DIP type package designed for use in solid-state
stereo receivers.

Features:
Requires No Inductors
Low External Part Count
Only Oscillator Frequency Adjustment Necessary
Integral Stereo/Monaural Switch 75mA Lamp Driving Capability
Wide Dynamic Range: 0.5 to 2.8V(p-p) Composite Input Signal
Wide Supply Range: 8V to 14V
Excellent Channel Separation Maintained Over Entire Audio Frequency Range
Low Distortion: Typically 0.3% THD at 560mV (RMS) Composite Input Signal
Excellent SCA Rejection

Replaces:
ECG801, GEIC-35, SK3160
