Data Sheet

NTE992
Integrated Circuit
Quad, Single Supply Operational Amplifier

Description:
The NTE992 is an internally compensated Norton operational amplifier in a 14-Lead DIP type package
designed specifically for single positive power supply applications found in industrial control systems
and automotive electronics. This device contains four independent amplifiers - making it ideal
for applications such as active filters, multi-channel amplifiers, tachometers, oscillators, and other
similar usages.

Features:
Single-Supply Operation
Internally Compensated
Wide Unity Gain Bandwidth: 4MHz Typ
Low Input Bias Current: 50nA Typ
High Open-Loop Gain: 1000V/V Min
Large Output Voltage Swing: (VCC -1) VP-P

Replaces:
ECG992, SK3688

Additional Model #'s
76-NTE992
NTE992
