Model SS-204A:
Screw-on connection

These mounts were specifically designed to allow antenna installations on vehicles where other mounts may not work. The primary goal was to offer a mount that could be affixed to a vertical inner door jamb such as that which might be found on the rear or side door of a cargo type van. Since the mounting screws are meant to be on the inner edge of the jamb, visible holes in the vehicle body are eliminated. Like many other Firestik mounts, the versatility of these mounts go well beyond their targeted use. When you hold this mount in your hand you will start to recognize all of the mounting possibilities. Chances are, you will find several locations to mount it on your vehicle. For antennas up to 4ft in length.

In order to give you many years of trouble free use, the bracket parts and mounting hardware is made of stainless steel. The bracket is 1.5" (38mm) wide and has a 2" (50mm) reach for mounting inside the door jamb. Overall, the mount is 4.2" (105mm) long. In order to compensate for the door jamb angles, the stud bracket will swivel a full 180 degrees, 90 in each direction. This adjustment feature will let you mount the antenna on either the left or right side of the vehicle. Includes four #12 x 1/2" Philips panhead stainless steel sheet metal screws (use a #20, 0.161" drill for the screw pilot holes)

We have two models for you to choose from;

The SS-204 includes our K-4T2 antenna stud mount. Accordingly, it is fully compatible with coax cables that are terminated with ring terminal connections or those that are unprocessed at the mount end. In case of the later, we do supply all of the required ring terminals with this mount.

The SS-204A includes the K-4A, SO-239 base antenna stud mount. If the mounting situation allows for the required space to use a screw on coax connector (PL-259) on the mount end of the coax, this is the mount to choose.

Additional Model #'s
221-SS-204A
221-SS204A
SS-204A
SS204A

UPC: 716414201093
