Powerwerx MPPT-150-14.6, DC-to-DC Solar Charger Controller for Bioenno 12V LiFePO4 Batteries

Rated at 150 watts, the MPPT-150-14.6 solar controller is designed for charging Bioenno 12V type LifePO4 batteries. Input DC range from 16-25 VDC. Output is a constant 14.6 VDC. Rated at 12 Amps maximum. Smart charge controller design will automatically adjust charging output as required by batteries, no user adjustment needed

Powerwerx MPPT-150-14.6 is a MPPT (maximum power point tracking) controller is a DC to DC solar converter. This unit is rated at 150 watts and converts higher solar panel voltages down to 14.6 VDC which is more suitable for charging LifePO4 type batteries. The solar input is pre-wired with MC4 style connectors. The output comes pre-wired with the popular Anderson Powerpole 30A connector.

Specifications:
Controller Technology: MPPT (Maximum Power Point Tracking) Technology
Input Voltage: 16-25 VDC
Output Voltage: 14.6 VDC
Input Connector Type: MC4
Output Connector Type: Anderson Powerpole 30A
Maximum Power: 150 Watts
Maximum Current: 12 Amps
Battery Type: Bioenno LiFePO4 or equivalent
System Type: 12 VDC (DC to DC converter)
Controls: Automatic (no user adjustments required)
Conversion Efficiency: 95%
IP Rating: IP67
Short Circuit Protection: Yes
Over Temperature Protection: Yes

Additional Model #'s
78-MPPT-150-14.6
78-MPPT15014.6
MPPT-150-14.6
MPPT15014.6

UPC: 840128902219
