Data Sheet

NTE1380
Integrated Circuit
Audio Power Amplifier, 14W

Description:
The NTE1380 is a monolithic integrated circuit in a 5-Lead TO220 type package intended for use as
an audio class AB amplifier. Typically, it provides 14W output power (THD = 0.5%) at VS = ±14V/4?.
This device provides high output current and has very low harmonic and cross-over distortion. Further,
the NTE1380 incorporates a short circuit protection system comprising an arrangement for automatically limiting the dissipated power so as to keep the working point of the output transistors within their safe operating area. A thermal shut-down system is also included.

Replaces:
ECG1380

Additional Model #'s
76-NTE1380
NTE1380

UPC: 768249034018
